2015 EC200SXV50-U44-4B Toshiba machine
HORIZONTAL INJECTION MOULDING MACHINES
| Type | All Electric |
| Clamping Force Tonnage | 198.4 T |
| Shot Volume (PS) | 8.3 oz |
| Shot Volume (PE) | 6.5 oz |
| Screw Diameter | 1.77" |
| Maximum Injection Pressure | 22900 psi |
| Maximum Holding Pressure | 22900 psi |
| Screw Speed STD | 285 rpm |
| Injection Rate STD | 19.4 ft³/min. |
| Injection Rate High Speed | 34 ft³/min. |
| Screw Torque STD | 3.3 |
| Plasticizing Capacity (PS) High Torque | 1.2 oz |
| Tie Bar Distance H | 22" |
| Tie Bar Distance V | 20.1" |
| Platen Dimension H | 31.1" |
| Platen Dimension V | 29.1" |
| Clamp Stroke | 17.7" |
| Maximum Daylight | 41.3" |
| Mold Height Min | 7.9" |
| Mold Height Max | 23.6" |
| Ejector Force | 5.5 T |
| Ejector Stroke | 5.1" |
| Injection Orientation | Horz |
| Hours | 37,500 hr. |
| Machine under power | Under power running with mould |
| Control | CNC (INJECTVISOR V30) |
| Dimensions | 18.7 X 4.9 X 6.2 |
| Weight | 15400 |
Tungsten Carbide Screws and Barrels and transformers for 460 volts.
